핵심 특징

상세 사양

• Mixing Capacity - Input Channels
  8 mono + 4 stereo + 1 Sound Pad + 2 FX
• Mixing Capacity - Mix Buses
  8 (mono)
• Mixing Capacity - Stereo Buses
  1
• Mixing Capacity - FX Buses
  2
• Mixing Capacity - Cue Buses
  1
• On-board DSP Processors
  Gate, Compressor, EQ, Sweet Spot Morphing
• I/O - Analog Input
  8 Combo (Mic/Line), 4 TRS (Line), 4 RCA (Line)
• I/O - Analog Output
  2 XLR, 8 TRS
• I/O - USB TO HOST
  2 (USB Type-C, MAIN: 32-bit/SUB: 16-bit)
• I/O - Phones
  4 TRS (100 mW+100 mW @40 Ohm)
• I/O - DC
  1 (Barrel type, DC power IN)
• I/O - microSD Card Slot
  1
• I/O - Bluetooth
  1 Bluetooth audio input (Bluetooth 5.0, A2DP)
• I/O - HDMI
  1 IN / 1 THRU (Audio/Video input/capture
• UI - Touch Screen
  4.3-inch touch screen
• UI - Faders
  16 x 60 mm fader
• UI - SEND Knobs
  16 x SEND knob
• UI - Rotary Encoders
  5 x rotary encoder (4 x screen knob, 1 x "TOUCH A
• Recording - USB
  22-track recording, 22-track playback
• Recording - USB (SUB)
  2-track recording, 2-track playback
• Recording - microSD Card
  Up to 16-track recording, 2-track playback
• Recording - Sampling Frequency Rate
  96 kHz - 44.1 kHz
• Audio - Signal Delay
  Less than 0.4 ms (INPUT to STEREO OUT @ Fs=96
• Audio - Frequency Response
  +0.0 / -0.5dB 20 Hz to 20 kHz, reference to
• Audio - Dynamic Range
  125 dB typ. (DAC to STEREO OUT)
• Audio - Total Harmonic Distortion
  Less than 0.002% 20 Hz to 20 kHz@+4 dBu (MIC
• Audio - Equivalent Input Noise
  -128 dBu typ. (Input Gain=Max.)
• Audio - Residual Output Noise
  -108 dBu (ST main off)
• Audio - Crosstalk
  -120 dB (adjacent INPUT/STEREO OUT channels
• Audio - Gain Range
  86 dB
• Power - Requirements
  DC16 V/2.4 A, PA-300C AC power adapter (100
• Power - Consumption
  38.4 W
• Dimensions - Width
  419 mm (16.5")
• Dimensions - Height
  96 mm (3.8")
• Dimensions - Depth
  319 mm (12.6")
• Dimensions - Net Weight
  4.9 kg (10.8 lb)
• Environment - Operating Temperature
  0 - 40 °C
• Environment - Storage Temperature
  -20 - 60 °C
• Video Capture - HDMI Input
  최대 4K/60fps, 1440p/120fps, 1440p/60fps
• Video Capture - USB Output
  4K/60fps~1080p/120fps SDR, 1080p/60fps SDR 또는 HDR
• Included Accessories
  Start Guide, Safety Guide, Steinberg Software
• Optional Accessories
  RK-MGX16 (Mixer Accessory)
