핵심 특징

상세 사양

• Type
  Powered mixer with 2 passive speakers
• 400BT - Mixing Channels
  8
• 600BT - Mixing Channels
  10
• 400BT - Inputs
  4 mono mic/line + 4 mono/2 stereo line
• 600BT - Inputs
  4 mono mic/line + 6 mono/3 stereo line
• Phantom Power
  +30V (CH1, 2)
• Outputs
  SPEAKERS OUT(L,R), MONITOR OUT, SUBWOOFER OUT
• Bluetooth
  Ver.4.1, A2DP v1.2, 최대 약 10m
• Reverb Foot Switch
  지원
• EQ HIGH
  HIGH Shelving: 8kHz
• EQ LOW
  LOW Shelving: 100Hz
• 600BT - EQ MID
  MID peaking: 2.5kHz
• On-board Processors
  SPX digital reverb (4 program)
• 400BT - Max Output (4Ω)
  400W (200W+200W Dynamic, 360W Continuous)
• 600BT - Max Output (4Ω)
  680W (340W+340W Dynamic, 560W Continuous)
• Speaker Type
  Two-way bass-reflex speakers
• Frequency Range (-10dB)
  55 Hz - 20 kHz
• Nominal Coverage (H/V)
  90° / 60°
• Floor Monitor Angle
  50°
• 400BT - LF Component
  400BT: 8인치(20cm) cone
• 600BT - LF Component
  600BT: 10인치(25cm) cone
• 400BT - HF Component
  400BT: 1인치(2.5cm) 콤프레션 드라이버
• 600BT - HF Component
  600BT: 1.4인치(3.6cm) 콤프레션 드라이버
• 400BT - Max Output Level (1m)
  125 dB SPL / speaker
• 600BT - Max Output Level (1m)
  129 dB SPL / speaker
• Power Requirements
  100V-240V 50/60Hz
• 400BT - Power Consumption
  30W(Idle), 70W(1/8 Power)
• 600BT - Power Consumption
  35W(Idle), 100W(1/8 Power)
• Pole Socket
  34.8-35.2mm, StageLok
• 400BT - Dimensions
  스피커 289x472x275mm, 믹서 308x180x116mm
• 600BT - Dimensions
  스피커 335x545x319mm, 믹서 348x197x135mm
• 400BT - Weight
  18.3 kg
• 600BT - Weight
  25.6 kg
• Included Accessories
  커버패널, 전원코드, 스피커케이블x2, 논스킵패드x12 등
• Optional Accessories
  FC5 (리버브 ON/OFF 풋스위치)
