핵심 특징

상세 사양

• System Type
  2-way, Bi-amp Powered Speaker, Bass-reflex
• Frequency Range(-10dB)
  52Hz-20kHz
• Coverage Angle
  H90 x V60 Constant Directivity Horn
• Crossover Type
  FIR-X Tuning (Linear Phase FIR Filter)
• Crossover Frequency
  2.1kHz
• Max SPL(Peak)
  131dB SPL
• LF Diameter
  12인치 Cone
• LF Voice Coil
  2인치
• LF Magnet
  Ferrite
• HF Type
  1인치 Throat Compression Driver
• HF Magnet
  Ferrite
• Enclosure Material/Color
  Plastic, Black
• Floor Monitor Angle
  50° Symmetrical
• Dimensions(WxHxD)
  376x601x348mm (14.8x23.7x13.7인치)
• Net Weight
  15.8kg (34.8lbs)
• Handles
  Side x2
• Pole Socket
  35mm
• Rigging Points
  Bottom x2 (M8x15mm Eyebolts)
• Amplifier Type
  Class-D
• Power Rating Dynamic
  1000W (LF:800W, HF:200W)
• Power Rating Continuous
  465W (LF:400W, HF:65W)
• Cooling
  Fan Cooling, 4 Speeds
• AD/DA
  24bit 48kHz Sampling
• HPF/LPF
  OFF, 100Hz, 120Hz, 24dB/Oct.
• Input Impedance
  INPUT1 3kΩ, INPUT2 10kΩ
• Power Requirements
  100-120V/220-240V, 50/60Hz
• Idle Power Consumption
  18W
• 1/8 Power Consumption
  74W
