핵심 특징

상세 사양

• Speaker Type
  2-way, Bi-amped Powered Speaker, Bass-reflex
• Frequency Range(-10dB)
  53Hz-20kHz
• Coverage Area
  H90 x V60
• Crossover
  1.8kHz FIR-X tuning (linear phase FIR)
• Max Output(Peak,IEC@1m)
  132dB SPL
• LF
  10인치 Cone, 2.5인치 Voice Coil
• HF
  1.75인치 Diaphragm, 1인치 Compression Driver
• Amplifier Class
  Class-D
• Power PEAK
  2000W (LF:1700W, HF:300W)
• Power RMS
  1000W (LF:850W, HF:150W)
• Cooling
  Fan Cooling, 5 Speeds
• Power Consumption
  120W(1/8 power), 35W(Idle)
• Power Requirements
  100-240V 50/60Hz
• A/D D/A Converters
  32bit/96kHz Sampling
• Cabinet Material
  Plastic (PP)
• Finish
  Black
• Pole Socket
  Ø35mm x2 (Bottom, 0° or -7°)
• Floor Monitor Angle
  55°
• Dimensions(WxHxD)
  310x502x310mm (12.2x19.8x12.2인치)
• Net Weight
  14.5kg (32.0lbs)
